Mean Roof Height Flat Roof

Additional edge zones have also been added for gable and hip roofs.

Mean roof height flat roof.

For building segment 1 determine the elevation of the highest point of the roof if it is a flat roof or the mean height between the tallest eave and tallest ridge if it is a pitched roof. For flat roofs the corner zones changed to an l shape with zone widths based on the mean roof height and an additional edge zone was added. Then repeat this process for each numbered segment. 12 l r 20 environmental loads wind loading structure is a regular shape located in a windborne debris region with terrain classification of exposure c and surrounded by flat terrain.

This measurement is best done on a bare roof because curled up roofing shingles will impair your measurement. The picture below shows the pitch of a 7 12 roof slope meaning that for 12 of horizontal measurement roof run the vertical measurement roof rise is 7. Z velocity pressure evaluated at any height z q h velocity pressure evaluated at the mean roof height h k z velocity pressure exposure coefficient defined in section 30 3 1 and given in table 30 3 1 evaluated at any height z only used for part 3 h 60 windward pressures. A frequently posed question when designing flat roofs is what upstand height do i need on the face of it a simple question with one may think a simple answer.

So why is mean roof height even important and why is it even listed on the plans. Subtract the average existing grade for segment 1 from the roof elevation for segment 1. Per asce 7 the mean roof height h is defined as the average of the roof eave height and the height to the highest point on the roof surface except that for roof angles of less than or equal to 10 the mean roof height is permitted to be taken as the roof eave height. The mean roof height would be the average of 12 plus 22 67 or 17 33 as shown on the building plans.

For gable and hip roofs in addition to the changes in the number of the roof wind. Note that the roof live load falls between the limits giv en. Most of the time the simple answer is 150mm above the finished roof level.
